• 主要特点:
  • Capacities 1/2 Ton through 100 Ton
  • All-steel construction for extreme durability
  • Low headroom and lightweight design for ease of use
  • Slip clutch prevents lifting damaging loads beyond rated capacity
  • Limited number of parts simplifies and reduces maintenance

• 主要应用:

  Capabilities To Count On


  • 8-foot standard lift (12-foot for 10 Ton and greater),
    nonstandard lifts and hand chain drops are also available.
  • Grade 100 heat-treated manganese alloy load chain resists
     abrasion and wear while minimizing chain weight.
  • Forged and heat-treated alloy steel hooks are designed to
    open slowly, without fracturing under excessive loads.
  • Test certificate verifies that every hoist has been factory
     load tested to 125% of rated capacity, in accordance with
     AS ME B30.16 requirements.

• 产品规格:

  Cap. (Tons)	Hoist Product Code	Headroom C (in)	Std. Lift (ft)	Pull to Lift Load (lbs)	a (in)	b (in)	d (ft)	e (in)	f (in)	g (in)	x (in)	Overhaul Ratio	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Shipping Weight Approx. (lbs)	Weight for Add'l One Foot of Lift (lbs)
  1/2	CB005	11.2	8	48	6.2	6.3	8.0	2.7	3.9	1.1	3.5	25	5.0 x 1	22	23	1.0
  1	CB010	11.6	8	58	6.4	6.3	8.0	2.8	3.9	1.1	4.0	43	6.3 x 1	25	26	1.2
  1 1/2	CB015	13.8	8	70	6.7	7.2	8.0	3.1	4.4	1.3	4.7	57	7.1 x 1	32	33	1.4
  2	CB020	14.8	8	72	7.2	8.0	8.0	3.4	4.9	1.4	4.9	70	8.0 x 1	41	43	1.6
  2 1/2	CB025	16.5	8	66	7.6	9.2	8.0	3.6	5.6	1.6	5.4	99	9.0 x 1	56	58	1.8
  3	CB030	20.1	8	72	6.7	9.3	8.3	3.1	6.4	1.7	5.8	114	7.1 x 2	49	53	2.1
  5	CB050	23.6	8	68	7.6	11.1	10.0	3.6	7.6	1.8	6.8	198	9.0 x 2	85	89	3.0
  8	CB080	30.3	8	75	7.6	14.7	10.3	3.6	10.0	2.9	10.8	297	9.0 x 3	124	131	4.2
  10	CB100	29.9	12	72	7.6	17.2	14.9	4.4	12.1	2.9	11.6	396	9.0 x 4	186	203	5.5
  15	CB150	40.2	12	74	10.6	19.4	15.9	4.7	13.3	3.1	12.6	594	9.0 x 6	346	368	7.9
  20	CB200	46.5	12	72 x 2	14.7	29.4	16.3	7.4	14.7	3.2	13.8	396 x 2	9.0 x 8	524	678	10.9
  30	CB300	51.2	12	86 x 2	15.9	29.4	16.3	8.0	14.7	4.1	15.7	495 x 2	9.0 x 10	690	889	13.3
  40	CB400	58.3	12	86 x 2	19.8	29.9	16.6	9.9	15.0	4.1	17.5	693 x 2	9.0 x 14	1068	1398	18.2
  50	CB500	61.4	12	98 x 2	21.4	31.3	16.6	10.7	15.7	4.4	18.4	792 x 2	9.0 x 16	1422	1752	20.6
  80	CB800	100.8	12	86 x 4	29.9	55.2	15.9	13.8	27.6	5.1		693 x 4	9.0 x 28	3392		36.3
  100	CB1000	125.2	12	98 x 4	31.3	56.9	14.6	15.7	28.4	7.3		792 x 4	9.0 x 32	6525		41.2

• Many Benefits From More Features:

  Experience exceptional durability • thanks to all-steel
  construction featuring rugged gear case enclosure and
  handwheel cover.
  • Enjoy increased lifting height thanks to low headroom.
  • Compact design results in lightweight and easy portability.
  • Minimize manual effort thanks to efficient drive train.
  • Standard slip clutch device prevents the hoist from being
     used to lift damaging loads beyond rated capacity.
  • Double pawl springs provide redundancy for reliable
     operation of brake mechanism.
  • Get reliable braking with double enclosed brake cover that
